Product Details:
Payment & Shipping Terms:
|
| Volumn: | 1~2m³ | Power Installation: | 22~37kw |
|---|---|---|---|
| Capacaity: | 60~200kg/h | Dielectric Consistence: | 4~6% |
| Impeller Knife: | CAST IRON | Material Code: | Carbon Steel Or Stainless Steel |
| Highlight: | 200kg/h Horizontal Hydra Pulper,Horizontal Hydra Pulper |
||
Horizontal Hydra Pulper
This hydra pulper is used in the process of pulp making . Hydra pulper is capable of disintegrating the wasted paper into pulp and meanwhile screening out the impurities and maintaining certain consistency of pulping. Hydra pulper is mainly composed of tank, rotor, flying knife and screen plate. Carbon steel or stainless steel is optional for the material of tank.
Advantages of Horizontal Hydrapulper
1. Suitable for production with lower capacity and lower energy consumption
2. Can separate the impurity from pulp slurry without using vibration filter
Specification:
| Model of Machine | Volume | Capacity | Consistency of pulp | Power | Material of tank | Material of knife plate | |
| Horizontal hydra pulper | 1 | 1m³ | 60~90kg/hr | 4~6% | 22~37kw | carbon steel/ stainless steel |
carbon steel/ stainless steel |
| 2 | 1.5m³ | 100~150kg/hr | 4~6% | 22~37kw | carbon steel/ stainless steel |
carbon steel/ stainless steel |
|
| 3 | 2m³ | 160--200kg/hr | 4~6% | 22~37kw | carbon steel/ stainless steel |
carbon steel/ stainless steel |
Illustration of machine:
